Attesting to the strength of our drawer boxes:
• Full four-sided box design of 3/4" thick TFL (thermally fused laminate) material
• 8mm diameter fluted wood dowel pin structural joint connection using PVA glue
• Removable overlay fronts / adjustable for alignment
• Drawer bottom 1/4" thick Grade 220 MDF (Medium Density Fiberboard) with TFL
• Drawer bottom mechanically captured in groove, PVA glued and stapled to sides
every 4" – out of sight on underside of drawer
• Under heavy side load testing, the drawer side material fails – not the PVA glued joint
• 1/2" thick material remaining from drawer bottom edge and exterior of side. Drawer slide screw insertion does not cause core or surfacing failures.
• Easily passes SEFA drawer mechanical properties testing for strength
|
