Jack Ganssle - a well-known tech expert - raves about this scope in these videos, saying "it's a bargain at $379 - I highly recommend this device!" (watch in part 2 where he even uses the word 'astonishing'!): Part 1 and Part 2.

Manufactured by specialist test equipment manufacturer Siglent and housed in an attractive, compact case, this 100MHz scope offers all you need for electronic circuit design and debugging, product quality control, or education and training.

All SDS1000 series products use unique EasyHunting™ technology in their waveform capture.  EasyHunting™ was created by Siglent's own research and development team. It combines unique hardware circuitry and software calculation algorithms to give the Siglent SDS1000 Series greater accuracy in capturing waveforms compared to competitors' products. As real-life test results attest, the SDS1000 series shows more realistic and steady intricate waveforms compared to other similar oscilloscopes. If you want stable signal displays, choose the SDS1000 series, which shows such perfect waveforms that you will think they are calculated mathematical functions!

Siglent's SDS1102CML Oscilloscope is a versatile dual-channel digital oscilloscope with built-in single-shot bandwidth of 100MHz, single real-time sampling rate up to 1GSa/s and equivalent sampling rate up to 50GSa/s.  It has a huge memory depth of 2Mpts, features a large, 7-inch color LCD and unique digital filter functions that allow users to use high pass, low pass, band pass and band stop digital filters to extract noise from readings.  It has multiple triggering options (Edge, Pulse, Video, Slope and Alternative). It includes the ability to export data via the USB and RS-232 ports for PC analysis at a later time using the included software package, which also enables remote operation of the oscilloscope.

Don't be surprised if your friends with other scopes are jealous of your SDS1102CML's larger screen, separate Ch1 & Ch2 controls, variable persistence, digital channel filtering, automatic measurements, etc.

Until next month!

Sincerely,

Saelig Company, Inc.

CEO

P.S. Want more details about this scope?  Here they are!  Siglent Technologies has been providing high quality digital storage oscilloscopes to customers all over the world, exporting to more than 40 countries. Siglent is fast becoming one of the leading Far East DSO manufacturers - with a growing worldwide reputation. Over 60 technical engineers with many years of experience work in Siglent's R&D center, developing sophisticated DSOs to meet customers' increasing needs.  In fact, they manufacture test equipment for several other very well known brands.

SDS1102CML

• 100MHz  1GSa/s sample rate
• 7''TFT-LCD display (wide 8 x18 grids)
• Channels: 2CH+1EXT
• 1GSa/s sampling rate, 2Mpts memory depth
• 6 digit hardware frequency counter, real time counting display
• Supports SCPI programming, external command control
• Interfaces: USB Device, USB Host, RS-232, Pass/Fail
• Unique separate digital filter and data recorder function on each channel (high-pass, low-pass, band-pass, band-stop)
• Embedded 12 languages, online help, one key storing and one key printing
• Rise time: < 3.5ns
• Input impedance: 1Mohm 17pF
• Vertical sensitivity: 2mV-10V/div
• Vertical resolution: 8bit
• Trigger source: CH1, CH2, Ext, Ext/5, AC Line
• Trigger types: Edge, Pulse, Video, Slope, Alternative
• Math Operation: +, -, �-, ÷, FFT
• Max input voltage: ±400V (DC+AC Pk-Pk), CAT I, CAT II
• Internal storage: 2 groups of reference waveform, 20 groups of setting, 10 groups of waveform
• External storage: Bitmap save, CSV save, Waveform save, Setting save
• Power: AC 100-240V, 45Hz-440Hz, 50VA Max
