The AERA Technical Committee offers the following information regarding a valve length caution on 2011-2020 Ford 3.5L Ecoboost Engines. This bulletin advises members of two different overall lengths of the exhaust valves depending on the year model of the engine.

From 2011-2016, Ford used an exhaust valve with an overall length of 3.7560” (95.402 MM). During the year range of 2017-2020 the overall valve length was increased by .570” to an overall length of 4.3250” (109.855 MM).

The AERA Technical Committee offers the following information regarding the drive gear method for oil pumps on 2015-2023 Ford 2.7L Ecoboost engines. It has been reported that the drive gear for the oil pump can be either a belt or a chain depending on the year range.

When ordering a new oil pump for this engine, you must know which drive gear method is being used. To make sure that you are ordering the correct parts, AERA offers the following information to reference when ordering a new oil pump.

Factory OE and examples of specific aftermarket specifications

By Mike Mavrigian

Applying the correct tightening values for threaded engine fasteners is critical for any engine build. Listed here are both factory OEM values, some of which involve a torque-plus-angle tightening method, and OEM and aftermarket values which require only a tightening-by-torque (or by monitoring rod bolt stretch) approach. Especially with regard to main cap bolts, cylinder head bolts and connecting rod bolts, it is imperative to follow the correct tightening procedures depending on the use of OEM bolts or aftermarket high performance fasteners. Each requires a different tightening method. These OE bolts require a torque-plus-angle method, while aftermarket fasteners require only a torque value. Also, since the OEM main cap, cylinder head and rod bolts are torque-to-yield, they should not be re-used. This also holds true for the crankshaft bolt that secures the crankshaft pulley. The OEM crank bolt is designed as a one-time use bolt and should never be re-used.

Chuck Lynch and Steve Fox discuss engine-related technical information and machining procedures, as well as invite guest hosts to share their knowledge.
